| Product Line | Driveline & Axles |
| Category Name | Driveline Components |
| Part Type | Universal Joint Strap Kit |
| Alternate Part Name | Retainer Kit, Bearing Strap Kit |
| Application Type | Semi-Trucks, Heavy Duty Trucks |
| Series | 1710/1760/1810 |
| VMRS Code | 24002072 |
| Material | Steel |
| Bolt Head Style | Flanged 12-Point |
| Bolt Thread Length | 1.000 in. |
| Compatible Bearing Cap Diameter | 1.938 in. |
| Distance Between Bolt Holes | 2.806 in. |
| Drive Shaft Bolt Specification | 1/2 in. - 20 |
| Retainer Type | Bearing Cap Retainer |
| Bolt Grade | 8 |
| Bolt Torque | 125 ft-lb. |
| Net Weight | 0.77 lb. |
| Cross References | 10046, 1658835C91, 2104-657018X, 2104657018X, 212214X, 25-657018X, 25657018X, 6.5-70-18X, 6.57018X, 65-70-18X, 657018X, 752657018X, JKT-6926, JKT6926, KT-17SB, KT17SB |
| Intended Application | - Designed for 1710, 1760, and 1810 series U-joints. Commonly found in the most demanding commercial and heavy-duty vehicle applications:
- Heavy-haul trucks and semi-trailers, Construction machinery and off-road equipment, Excavators, loaders, graders, Large buses and public transport vehicles, High-capacity industrial and commercial vehicles, utilizing driveshafts with 1710, 1760, and 1810 series U-joints.
|
| BOM | - 2 Strap
- 4 Drive Shaft Bolt
|
